Bot Design Patterns

different ways to make different bots

Nov 11, 2014

In the antediluvian days before Google found everything for us, personal software agents were going to continuously do our bidding in cyberspace, tracking down air fares, making stock trades and otherwise doing futuristic things that we soon wouldn't be able to live without. The anxiety of Y2K rose and crested, and the messianic aura of agents was washed away by more centralized and effective solutions.

The aspirational residue did yield some nuggets, and the idea has found partial success in the form of the bot. In the popular imagination bots exist on Twitter as art projects or as marketing machines or as the perfect online dating scandal.

Bots can be characterized by asking a few questions, and from these answers we can tell something about their implementation and what it takes to build one: Do they react to messages? Do they know who they are talking to? Can they learn from what was said? Do they know where the conversation is taking place? Do they remember the overall conversation?

From this, we can classify bots into one of six types:

  • Notifiers
  • Reactors
  • Space Reactors
  • Responders
  • Space Responders
  • Conversationists

Each of these have progressively more complex context that the bot is operating in. Most chat mediums have different message types, where message can be directed towards or private to a particular user. Confounding things further, some have a native concept of spaces, generally called a room or a channel, and as we treat people differently in different context the bot will also need to be aware of the difference context that the conversion is taking place. We can call those services Spaced.

Service Spaced Notes
SMS No Groups are a dynamic list of people
Desktop Notifications No Stuck on one computer
Push Notifications No One way communication
AIM No Group chat not core usage
GChat No Group chat not core usage
iMessage No Groups are a dynamic list of people
Twitter No Lists aren't groups
Yammer Yes Sorta
IRC Yes Channels
HipChat Yes Rooms
Slack Yes
Campfire Yes Rooms

Keeping track of User / Space context is more challenging than just User context

Notifiers

Notifiers are the "simplest type"of bots, in the sense that the messaging logic is a minor part of the overall program. As a consequence they are the most common and the most varied.

  • Broadcast a message based upon an external source
  • Don't react to messages, so the answers to all the other questions are irrelevant.

The trick in Notifiers is in figuring out what to say, not sending the message.

# Twitter Example
message = "Hello, World"
client.update( message )
# AppleScript from the command line example
$ MESSAGE="Hello, World"
$ /usr/bin/osascript -e "display notification \"$MESSAGE\""
# Using the terminal-notifier gem
require 'terminal-notifier'
TerminalNotifier.notify "\u2705 green!", :title => "Hello, World"

These are best implemented by having one program generate the information, and sending that to another program that sends the message to the chat service. This could be a monitoring agent that is checking to see if a URL is responding, and if not, sends an alert. It could be a build process that returns a success or failure message.

It could be a program that selects "the next word" from a lists of words and tweets one out every hour. Or it could make a bunch of API calls to different services, correlate that with information from a database, do more complicated calculations, and then post it. There's a bot that monitors the top links on hacker news, so it needs to pull down a list of top content, keep track of if it's tweeted it out before, and then send out the message. The sending part is simple, but the overall bot may not be.

Reactors

Reactors take action based upon incoming messages, but have no memory of who it's talking with or what space it's talking in. The who and where maybe in the message headers, and the bot can return the message in the correct place, but there is no bot-persisted memory of them.

  • Reacts to messages on the chat service
  • Doesn't remember anything that was said

The basic idea is that a reactor gets a message, does something with it, and moves on. A lot of twitter bots follow this pattern, where they are looking at things on the stream and commenting upon them.

on_message( message ) = ->
  result = act_on_message( message )
  message.reply( result )

For example, here's something that listens for tweets matching the string not a feminist and reacts by tweeting that that user isn't a feminist:

streaming_client.filter(track: "not a feminist") do |object|
  if object.is_a?( Twitter::Tweet ) && object.user.user_name != BOT_NAME
    client.update( ". @#{object.user.user_name} is not a feminist" )
  end
end

It could do something more interesting, like looking for an image url, downloading it, running it through ImageMagick, posting it to S3, and then tweeting it back out. But since the bot itself keeps no message or user state, we consider it a reactor.

Message Dispatching

Here we reach a phase change in the level of ambient complexity of the bot. Simple Reactors respond to all messages the same way, relying on the filter to select messages that it cares about. More complex reactors need to figure out what message it's being sent and reply differently:

Case loop:

on_message( message ) = ->
  dispatch( message )

dispach( message ) = ->
  case message.text
    when /^echo/
      do_echo( message )
    else
      message.reply( "Don't know what you mean" )

do_echo( message ) = ->
  message.reply( message )

Command objects:

on_message( message ) = ->
  dispatch( message )

dispatch( message ) = ->
  command = find_command_object( message )
  command.execute( message )

echo_command.execute( message ) = ->
  message.reply( message )

This can also be done using metaprogramming, something like this:

class Dispatcher
  dispatch( message ) = ->
    if reponds_to? message.command
      self.send( message.command, message )

class MyBotClass < Dispatcher
  echo( message ) = ->
    message.reply( message )

bot = MyBotClass.new

on_message( message ) = ->
  bot.dispatch( message )

That is nonsense pseudo code, but a lot of chat bot libraries focus in on that area doing something very similar to what Thor does for command line programs.

Space Reactors

Space Reactors, in addition to having an awesome name, react to incoming messages, and know where they are receiving a message. The bot has memory of the place, and will respond to the user differently depending upon where the conversation was taking place.

  • Reacts to messages on the chat service
  • Knows where its being addressed
  • Doesn't remember anything that was said

When a reactor is run in on Spaced chat medium, it needs to factor in where the message was received. Instead of having user and message to work with, it now has user, message, and space.

You can either find the space within each of the commands:

class MyBot < Dispatcher
  wtf( message ) = ->
    space = find_space_from( message )
    commit_message = space.last_commit_message
    message.reply( commit_message )

bot = MyBot.new

on_message( message ) = ->
  bot.dispatch( message )

Or locate the commands inside of the space, which lets you separate out which commands are available depending the properties of the space.

class PublicSpaceReactor < Dispatcher
  wtf( message ) = ->
    message.reply( "This space has no commits" )

class ProjectSpaceReactor < Dispatcher
  wtf( message ) = ->
    message.reply( project.last_commit_message )

class SpaceDispatcher < Dispatcher
  dispatch( message ) = ->
    space = find_space( message )
    responder = nil
    if space.project?
      responder =  ProjectSpaceReactor.new( space.project )
    else
      responder = PublicSpaceReactor.new
    responder.dispatch( message )

bot = SpaceDispatcher.new

on_message( message ) = ->
  bot.dispatch( message )

If you have a HipChat bot and have a room for each company project, and you want to have the bot respond to wtf with the last commit message on github. The first thing that you need to do is look at which room the message came from, and correlate that a list of repositories, then make a Github API call, and finally post the commit message back to the room.

  # This is a lita based bot, which provides dispatching
  # so we find the space inside of the command
  def wtf(response)
    project = find_project response.message.source.room
    message = project.last_commit_message
    response.reply message
  end

The find_project method implies that you now need to have persistent state associated with the Space, in this case the unspecified project object. It's not just a matter of making sure that your reply goes to the correct place, but that what you reply will changed based upon where the person said it.

Responders

Responders listen for messages and remember what was said to them. They are different from Reactors because they have persisted User state, and so can learn something from the user.

  • Reacts to messages
  • Knows who they are talking to
  • Can learn from what was said

It's natural here to include the dispatching inside of the object that keeps track of the user state. Here's a pseudo example of a bot that lets you update your nickname. First by loading the user inside of the Bot:

class NickBot < Dispatcher
  nick( message ) = ->
    user = User.load_from_datastore( message.user )
    user.nickname = message.arg1
    user.save
    message.reply( "Your nick name has been updated to " + message.arg1 )

bot = NickBot.new

on_message( message ) = ->
  bot.dispatch( message )

But it may also make sense to create different types of dispatchers for different users, in this pseudo code there are 3 different types of responders and depending upon who is sending the message different functions are available to them:

class AnonymousUserResponder < Dispatcher
  nick( message ) = ->
    user.nickname = message.arg1
    user.save
    message.reply( "Your nick name has been updated to " + message.arg1 )

class NamedUserResponder < AnonymousUserResponder
  comment( message ) = ->
    create_a_comment( user.nickname, message )
    message.reply( "Thanks for the message" )

class AdminResponder < NamedUserResponder
  restart( message ) = ->
    restart_server
    message.reply( "You've restarted the server" )

class UserDispatcher < Dispatcher
  dispatch( message ) = ->
    user = User.load_from_datastore( message.user )
    responder = nil
    if user.admin?
      responder = AdminResponder.new( user )
    elseif user.nickname?
      responder = NamedUserResponder.new( user )
    else
      responder = AnonymousUserResponder.new( user )
    responder.dispatch( message )

bot = UserDispatcher.new

on_message( message )
  bot.dispatch( message )

This example is misleading because in real life direct inherency doesn't scale well, as we'll see below.

Space Responders

Space Responder learn things about who is talking with them and the context in which they are speaking.

  • Reacts to messages
  • Knows who they are talking to
  • Can learn from what was said
  • Knows where its being addressed

The challenge here is how do you juggle the permutations of state. Lets take the example of a user is an admin in one project, where they can send commands to reboot the server, and in another project they can only open new tickets. In the basic case, you can do everything in each of your methods:

class ServerBot < Dispatcher
  restart( message ) = ->
    user = find_user( message )
    space = find_space( message )
    if space.is_admin?( user )
      restart_server
      message.reply( "Go go go" )
    else
      message.reply( "Sorry Charlie, try again" )

  ticket( message ) = ->
    space = find_space( message )
    ticket = space.create_ticket_message( message )
    message.reply( ticket.id + " has been created" )

bot = ServerBot.new

on_message( message ) = ->
  bot.dispatch( message )

Lets say that we had two different types of users, admins or not, and two different types of spaces, one that mapped to a project and another that mapped to a hangout area. We could expand out idea of the SpaceDispatcher to return a different command object based upon the combinations.

class SpaceDispatcher < Dispatcher
  dispatch( message ) = ->
    space = find_space( message )
    user = find_user( message )
    if !space.project?
      if space.is_admin?( user )
        AdminLobbyResponder.new( space, user ).dispatch( message )
      else
        LobbyResponder.new( space, user ).dispatch( message )
    else if space.is_admin?( user )
      AdminSpaceResponder.new( space, user ).dispatch( message )
    else
      ProjectResponder.new( space, user ).dispatch( message )

class LobbyResponder < Dispatcher
  vote( message ) = ->
    votes = space.tally_term( message )
    message.reply( "That totals: " + votes )

class AdminLobbyResponder < LobbyResponder
  topic( message ) = ->
    space.set_topic( message )
    message.reply( "Topic updated" )

class ProjectResponder < LobbyResponder
  ticket( message ) = ->
    ticket = space.create_ticket( message )
    message.reply( ticket.id + " has been created" )

class AdminProjectResponder < ProjectResponder
  restart( message ) = ->
    restart_server
    message.reply( "Server restarted" )

bot = SpaceDispatcher.new

on_message( message ) = ->
  bot.dispatch( message )

We're also using inheritance to include all of the methods that the regular user can do into the class that has all of the Admin methods. This pseudocode has turned into an unholey mixture of Ruby and CoffeeScript, so it probably isn't work doing into language details with this. But straight up inheritance doesn't work well for this type of reuse, and in our example project admins won't be able to change the topic. These commands would better be structured as mixins.

Conversationists

The final, and technically most complicated type of bot to write is a Conversationalist.

  • Reacts to messages
  • Knows who they are talking to
  • Can learn from what was said
  • Has conversational state
  • Knows where its being addressed

The basic structure is:

class Conversation < Dispatcher
  # knowledge collected during the course of the conversation #

  # state machine mapping conversion state #

  dispatch( message ) = ->
    # Store incoming message in log
    # interpret the response based upon the current state
    # print a message on state transition

class ChatBot < Dispatcher
  dispatch( message ) = ->
    user = find_user( message )
    conversation = user.current_conversation
    conversation.dispatch( message )

bot = ChatBot.new

on_message(message) = ->
  bot.dispatch( message )

The User object is responsible for keeping track of conversations. current_conversation can be smart enough to create a new conversation when things are stale or if there user explicitly closed out an active one.

Here is an example of code from a bot that asks you questions about where you are and what sort of food you are looking for. It searches a number of APIs in the background to see what information it can get from what you say. The code is written with an Adaptor to talk Twitter or GChat, and they both have a different idea of location. Sometimes it can get an accurate enough location the message metadata, but more likely it's too vague and it will ask you to clarify. (Not all of that logic is below, but its useful to demonstrate the use of the state machine.)

The knowledge attributes are what the bot knows in the conversation. Below you'll see an example of knowledge of the conversation from the state machine, knowledge of what as been said from previous messages, and knowledge of deduction from the content and context of the messages.

class ConversationResponder
  # State Machine
  workflow do
    state :new do
      event :process_message,  :transitions_to => :processing_location
    end

    state :processing_location do
      event :needs_location,    :transitions_to => :clarify_location
      event :location_clear,    :transitions_to => :has_location
    end

    state :clarify_location do
      event :process_message,   :transitions_to => :processing_location
    end

    state :has_location do
      event :needs_keywords,    :transitions_to => :clarify_keywords
      event :has_keywords,      :transitions_to => :processing_keywords
    end

    state :clarify_keywords do
      event :process_message,   :transitions_to => :processing_keywords
    end

    state :processing_keywords do
      event :needs_keywords,    :transitions_to => :clarify_keywords
      event :needs_location,    :transitions_to => :clarify_location
      event :found_places,      :transitions_to => :refining_selection
      event :no_places_found,   :transitions_to => :clarify_keywords
    end

    state :refining_selection do
      event :process_message,   :transitions_to => :processing_keywords
    end
  end

  # Knowledge Attributes
  def looking_for_location?
    !knows_location? || location_vague?
  end

  def knows_location?
    !lat.blank? && !lng.blank?
  end

  def location_vague?
    return false if location_range == "ROOFTOP" || location_range == "RANGE_INTERPOLATED"
    #Added by Jon so that zip codes are sufficient
    return false if location_range == "APPROXIMATE"
    #TODO: put more intelligence into this: eg location_range = "GEOMETRIC_CENTER" is good enough for Iowa but not for NYC
    true
  end

  def location_name
    if knows_location?
      status,address =  Geocode.reverse_geocode([lat,lng])
      return address
    else
      return nil
    end
  end

  def looking_for_places?
    places.count == 0
  end

  def have_keyword_messages?
    !keyword_messages.nil? && keyword_messages.length > 0
  end

  def keyword_messages
    @keyword_messages ||= messages.select{ |x| x.looks_like_keyword? && !x.is_a?( OutgoingMessage ) }
  end

  def keywords
    keyword_messages.collect { |x| x.search_terms }.join( ", ")
  end
end

Thats the shape of it

Notifiers, Reactors, Space Reactors, Responders, Space Responders, and Conversationists. Writing Notifiers and Reactors are more playful, and as you get into things later in the list you spend a lot more time dealing with code and logic complexity.

The distinction between a Spaced and Global chat medium is something that makes using chat libraries, and building Adapters to different services difficult. If the library was built with a Spaced service in mind it's pretty straightforward to make it work for one, but going the other way isn't swimming upstream.


Towards a taxonomy of Twitter Bots

BotSummit was a few days ago, and a bunch of people got together to talk about Twitter bots that they made largely as art projects. Here's a draft of a taxonomy of Twitter bots made by Tully Hanson. In the parlance of this post, these are mainly Notifiers and Reactors, with some possible Responders thrown in:

Twitter Bot Taxonomy

Here's the source document

Notifiers are interesting not because of their technology, but because of what they actually do. Here's a list of ideas that people came up with.


Agents of Note

Hubot from Github is a company chat bot written in Node

left_float

Hubot from Github:

GitHub, Inc., wrote the first version of Hubot to automate our company chat room. Hubot knew how to deploy the site, automate a lot of tasks, and be a source of fun in the company. Eventually he grew to become a formidable force in GitHub. But he led a private, messy life. So we rewrote him.

Image from Hubot site

Lita is similar to Hubot but written in Ruby

Lita homepage

left_float Image from Lita

Huginn is your agent, standing by

left_float

Huginn takes a bit to install, but it's a full on software agent of the old school.

Huginn is a system for building agents that perform automated tasks for you online. They can read the web, watch for events, and take actions on your behalf. Huginn's Agents create and consume events, propagating them along a directed graph. Think of it as a hackable Yahoo! Pipes plus IFTTT on your own server. You always know who has your data. You do.

We're just getting started, but here are some of the things that you can do with Huginn right now:

  • Track the weather and get an email when it's going to rain (or snow) tomorrow ("Don't forget your umbrella!")
  • List terms that you care about and receive emails when their occurrence on Twitter changes. (For example, want to know when something interesting has happened in the world of Machine Learning? Huginn will watch the term "machine learning" on Twitter and tell you when there is a large spike.)
  • Watch for air travel or shopping deals
  • Follow your project names on Twitter and get updates when people mention them
  • Scrape websites and receive emails when they change
  • Connect to Adioso, HipChat, Basecamp, Growl, FTP, IMAP, Jabber, JIRA, MQTT, nextbus, Pushbullet, Pushover, RSS, Bash, Slack, StubHub, translation APIs, Twilio, Twitter, Wunderground, and Weibo, to name a few.
  • Compose digest emails about things you care about to be sent at specific times of the day
  • Track counts of high frequency events and send an SMS within moments when they spike, such as the term "san francisco emergency"
  • Send and receive WebHooks
  • Run arbitrary JavaScript Agents on the server
  • Track your location over time
  • Create Amazon Mechanical Turk workflows as the inputs, or outputs, of agents. ("Once a day, ask 5 people for a funny cat photo; send the results to 5 more people to be rated; send the top-rated photo to 5 people for a funny caption; send to 5 final people to rate for funniest caption; finally, post the best captioned photo on my blog.")

Image "Odin, der Göttervater" by Carl Emil Doepler (1824-1905) - Wägner, Wilhelm. 1882. Nordisch-germanische Götter und Helden. Otto Spamer, Leipzig & Berlin. Page 7.. Licensed under Public domain via Wikimedia Commons - Link


Let me know cool things you build!
